We are specializes in ruggedized cameras designed to meet stringent environmental standards, particularly MIL-STD-810, ensuring reliable performance in demanding conditions.
Features:
- MIL-STD-810 Compliance: Engineered to endure extreme temperatures, humidity, shock, and vibration, these cameras are suitable for industrial, defense, and aerospace applications
- High-Speed Imaging: Utilize global shutter sensors to capture high-resolution images at impressive frame rates, essential for dynamic environments
- CoaXPress Interface: Support high-speed data transmission, facilitating efficient integration into machine vision systems
- Compact and Rugged Design: Built to fit into confined spaces while withstanding harsh conditions, ensuring durability and longevity
Specifications:
- Resolution: Varies from 1 Megapixel to 127 Megapixels (depending on model)
- Frame Rate: Varies from 1 fps to 228 fps
- Pixel Size: Range 3.2 µm x 3.2 µm to 3.45 µm x 3.45 µm
- Common Interfaces: CoaXPress, PCIe Gen 4, SDI, Camera Link, and USB 3.0
- Data Transfer Rates: Up to 50 Gbps (CoaXPress v2.0) for high-speed data transmission
- Dynamic Range: 65 dB to 70.8 dB
- Global Shutter: Most models (ideal for fast-moving objects)
- Rolling Shutter: Available in specific models for cost-effective applications
- Power Consumption: Range < 9 W to 15 W)
- Physical Dimensions: Width: 34 mm to 83 mm, Height: 22 mm to 78 mm, Length: 44 mm to 116 mm, Weight: 42 g to 500 g (without lens)
- Operating Temperature:: Range -40°C to +75°C (industrial grade) & Commercial Grade 0°C to +50°C
- Humidity Range: 10% to 90% RH (non-condensing)
- Lens Mounts: F-mount, EF-mount, Active EF-mount, M42-mount
For more information, please contact us.
